ZETTLER Magnetics specializes in the development, engineering and production of environmentally-friendly, safe, efficient and cost-effective power solutions including passive components for filtering, noise suppression, and EMI/EMC management. While most are built-to-spec designs for the diverse needs of our customers, off the shelf options are available for popular common mode, differential, drum, and PFC chokes.
| Part Number | Image | L (mH) | Rdc typ.(Ω)(Ta=25℃) | Rdc max.(Ω)(Ta=25℃) | Ie (A) (ΔT=40℃) | Saturation Current (10% drop) | Saturation Current (30% drop) | |
|---|---|---|---|---|---|---|---|---|
| XZM-RE28007 |  |  | 3.0±20% | 0.43 | 0.55 | 1.50 | 3.00 | 3.70 |
| XZM-RE28029 | | | 6.5±20% | 1.00 | 1.30 | 1.00 | 1.90 | 2.40 |
| XZM-RE28039 |  | | 6.0 Min | 0.49 | 0.65 | 1.70 | 1.50 | 1.80 |
| XZM-RE28056GP | | | 10.0±20% | 0.64 | 0.85 | 1.40 | 1.30 | 1.80 |
| XZM-RE28070GP | | | 11.0 Min | 1.23 | 1.60 | 1.10 | 1.10 | 1.40 |
| XZM-RE28080GP | | | 6.0 Min | 0.53 | 0.70 | 1.60 | 1.90 | 2.40 |
| XZM-RE28086GP | | | 10.0±20% | 1.51 | 2.00 | 1.00 | 1.70 | 2.10 |
| XZM-RE28086GP-1 | | | 12.0 Min | 1.67 | 2.20 | 0.90 | 1.20 | 1.60 |
| XZM-RE28090GP | | | 13.0±20% | 0.85 | 1.10 | 0.90 | 1.10 | 1.60 |
| XZM-RE28099GP | | | 10.0±20% | 0.95 | 1.25 | 1.20 | 0.90 | 1.30 |
| XZM-RE28102GP | | | 2.0±20% | 0.68 | 0.90 | 1.40 | 5.40 | 6.80 |
| XZM-RE30015 | | | 5.2±20% | 0.40 | 0.55 | 1.90 | 2.10 | 2.70 |
| XZM-RE30020 | | | 14.0±20% | 0.96 | 1.30 | 1.30 | 1.30 | 1.80 |
| XZM-RE30025-01 | | | 4.5±20% | 0.47 | 0.65 | 2.00 | 3.40 | 4.40 |
| XZM-RE30027 | | | 2.0±20% | 0.16 | 0.22 | 2.40 | 3.60 | 4.40 |
| XZM-RE30054 | | | 9.5±20% | 0.85 | 1.20 | 1.30 | 1.60 | 2.30 |
| XZM-RE30057 | | | 3.2±20% | 0.32 | 0.45 | 2.40 | 5.70 | 7.40 |
| XZM-RE30060 | | | 2.5±20% | 0.18 | 0.25 | 3.20 | 4.70 | 6.20 |
| XZM-RE30064 | | | 5.0±20% | 0.48 | 0.70 | 2.00 | 3.20 | 4.40 |
| XZM-RE30064-03 | | | 4.0±20% | 0.48 | 0.70 | 2.00 | 4.80 | 6.20 |
| XZM-RE30068 | | | 4.0±20% | 0.29 | 0.40 | 2.40 | 2.90 | 3.70 |
| XZM-RE30076 | | | 3.5±20% | 0.40 | 0.55 | 2.00 | 3.40 | 4.20 |
| XZM-RE30079 | | | 2.0±20% | 0.51 | 0.70 | 1.60 | 6.60 | 8.40 |
| XZM-RE30082 | | | 14.0±20% | 0.94 | 1.30 | 1.10 | 1.30 | 1.80 |
| XZM-RE30093 | | | 8.0±20% | 0.47 | 0.70 | 1.90 | 1.90 | 2.40 |
| XZM-RE30101 | | | 2.0±20% | 0.19 | 0.25 | 3.00 | 5.60 | 7.00 |
| XZM-RE30115VP | | | 6.2±20% | 0.38 | 0.55 | 1.80 | 2.20 | 2.70 |
| XZM-RE30129GP-1 | | | 2.5±20% | 0.48 | 0.70 | 2.00 | 7.00 | 8.60 |
| XZM-RE30142GP | | | 4.4±20% | 0.64 | 1.00 | 1.80 | 3.80 | 4.80 |
| XZM-RE30142GP-6 | | | 4.4±20% | 0.49 | 0.70 | 2.00 | 3.80 | 4.80 |
| XZM-RE30150GP | | | 4.8±20% | 0.65 | 0.90 | 1.50 | 2.90 | 3.60 |
| XZM-RE30156GP | | | 4.0±20% | 0.74 | 1.00 | 1.60 | 5.60 | 6.40 |
| XZM-RE30166VP | | | 2.0±20% | 0.18 | 0.25 | 2.60 | 3.80 | 5.00 |
| XZM-RE301801GP | | | 6.2±20% | 0.42 | 0.60 | 1.90 | 1.80 | 2.30 |
| XZM-RE301810-01 | | | 4.5±20% | 0.55 | 0.80 | 1.60 | 2.30 | 2.90 |
| XZM-RE301810-03 | | | 3.8±20% | 0.41 | 0.60 | 1.80 | 2.50 | 3.00 |
| XZM-RE302308 | | | 10.5±20% | 0.92 | 1.30 | 1.20 | 2.30 | 3.00 |
